How to locate M2810Z5 E1.S NVMe device?
Question:
How to locate M2810Z5 E1.S NVMe device?
Answer:
In Linux environment. We can use the
process below to locate M2810Z5 E1.S NVMe device.
1.
$nvme list-subsys. <It
displayed NVMe device’s PCIe address.>
2.
$sudo dd if=/dev/nvmexn1
of=/dev/null. <Then the E1.S NVMe slot LED will be blinking.>
3.
Press “Ctrl + C” to stop it.
The E1.S NVMe PCIe address as below.
